Name: Danfoss EMP 2 Series Pressure Transmitters 084G2106 084G2107 084G2108 084G2109 084G2110 084G2111
Brand: Dandoss
Price: 120 USD

Brand Name : Dandoss

Model Number : 084G2109

Certification : -

Place of Origin : Japan

MOQ : 1

Price : USD120/PC

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 1000

Delivery Time : 1week

Packaging Details : Original

Condition : new and original

Product name : thermostat

Selling Units : Single item

Single package size : 10X10X10 cm

Single gross weight : 1.000 kg

Contact Now

Product details

Gross weight	1.058 Kilogram
Net weight	0.98 Kilogram

Volume	2.447 Liter
EAN	5702423020164

+ supply	P
- common	N
Accuracy, max. [±FS%]	1 %
Accuracy, typical [±FS%]	0.5 %
Approval	ABS BV CCS DNV GL GOST POCC KR LR NNK RINA
CE evaluated	Yes
China RoHS compliance	Out of scope
Compensated temp. range [°C] [max]	70 °C
Compensated temp. range [°C] [min]	0 °C
Compensated temp. range [°F] [max]	158 °F
Compensated temp. range [°F] [min]	32 °F
Electrical connection	Terminal block
Electrical connection size	Pg 13.5
Enclosure rating IP	IP65
EU RoHS compliance	Out of scope
Flush diaphragm	No
High Clipping Level	22.4
In scope of WEEE and contain batteries	No
International Article Number	5702423020164
Intrinsically safe	No
Low Clipping level	3.6
Medium temperature range [°C] [max]	70 °C
Medium temperature range [°C] [min]	-10 °C
Medium temperature range [°F] [max]	158 °F
Medium temperature range [°F] [min]	14 °F
Non-linearity BFSL [±FS%]	0.3 %
Output signal	Current
Output signal [mA] [max]	20 mA

Output signal [mA] [min]	4 mA
Overload pressure max. [bar]	20 bar
Packing format	Multi pack
Pressure connection notes	EXT. G1/4 INT
Pressure connection size	1/2
Pressure connection standard	EN 228-1
Pressure connection type	G
Pressure Male/Female	Male/Female
Pressure range [bar] [max]	10 bar
Pressure range [bar] [min]	0 bar
Pressure range [psi] [max]	145 psi
Pressure range [psi] [min]	0 psi
Pressure reference	Gauge (relative)
Product group	Sensors
Product Name Description	Pressure transmitter
Pulse-snubber	No
Quantity per packing format	8 pc
REACH Candidate List substances	Lead (CAS no. 7439-92-1)
Response time max. [ms]	4 ms
SCIP dossier no.	6010d1e2-f473-4af2-afdd-bb494bdd0100
SCIP dossier product name	EMP
Specification key	EMP 2-2011-F6CD24-2
Supply voltage [V] DC [max]	32 V
Supply voltage [V] DC [max]	32 V
Supply voltage [V] DC [min]	12 V
Supply voltage [V] DC [min]	12 V
Type	EMP 2
UK RoHS compliance	Out of scope
